EP20K160EFC484-2X

The EP20K160EFC484-2X is an APEX-20KE series Field Programmable Gate Array (FPGA) in a 484-BBGA package designed for board-level integration. It provides a balance of programmable logic and embedded memory suitable for moderate-density custom logic, interface bridging, and system integration tasks.

Key electrical and environmental parameters include a core supply range of 1.71 V to 1.89 V, commercial-grade operation from 0 °C to 85 °C, surface-mount packaging, and RoHS compliance.

Key Features

• Logic Capacity The device contains 6,400 logic elements to implement custom combinational and sequential logic functions.
• Embedded Memory Approximately 0.08 Mbits (81,920 bits) of on-chip RAM for small data buffers, FIFOs, and state storage.
• I/O Density 316 available I/O pins to support multiple parallel interfaces and board-level connectivity.
• Power Core operating voltage range of 1.71 V to 1.89 V to match system power rails and design constraints.
• Package and Mounting 484‑BBGA (supplier package listed as 484‑FBGA, 23×23) in a surface-mount form factor for compact PCB layouts.
• Temperature and Grade Commercial-grade device rated for 0 °C to 85 °C operation.
• Environmental Compliance RoHS-compliant construction for regulatory and manufacturing compatibility.

Typical Applications

• Embedded Control and Interface Logic Use the device’s 6,400 logic elements and 316 I/Os to implement custom control paths, protocol translators, and peripheral interfaces.
• Prototyping and System Integration The programmable fabric and on-chip RAM support rapid prototyping of custom logic blocks and integration of glue logic on production boards.
• Compact Board-Level FPGA Integration The 484-BBGA surface-mount package and 23×23 footprint enable space-efficient placement on compact PCBs.

Unique Advantages

• Balanced Logic and Memory: 6,400 logic elements paired with approximately 0.08 Mbits of embedded RAM provide a compact platform for a range of mid-density designs.
• High I/O Count: 316 I/O pins allow flexible interfacing to multiple external devices and buses without external IO expanders.
• Compact FBGA Package: The 484-BBGA / 484-FBGA (23×23) package supports dense PCB layouts while keeping the device surface-mount compatible.
• Controlled Power Envelope: A defined supply range of 1.71 V to 1.89 V simplifies power-supply planning for systems targeting this FPGA family.
• Commercial Grade and RoHS Compliant: Rated for 0 °C to 85 °C operation and RoHS-compliant, suitable for standard commercial electronic products.

Why Choose EP20K160EFC484-2X?

The EP20K160EFC484-2X delivers a practical mix of programmable logic, embedded memory, and I/O density in a compact FBGA package for commercial electronics. Its defined supply range and temperature rating make it appropriate for mid-density control, interface, and prototyping applications where board space and I/O capability are important.

Designers and procurement teams seeking a RoHS-compliant, surface-mount FPGA with 6,400 logic elements and extensive I/O will find this part suited to scalable, cost-conscious designs that require reliable, on-board programmable logic.

Request a quote or submit an inquiry for pricing, availability, and lead-time information for the EP20K160EFC484-2X.
