EP20K200BC356-1

The EP20K200BC356-1 is an APEX-20K® field programmable gate array from Altera in a 356-LBGA surface-mount package. It integrates 8,320 logic elements, approximately 0.106 Mbits of embedded memory, and 277 general-purpose I/O pins for configurable digital logic designs.

Specified for commercial operation, this device provides a fixed supply-voltage range and package density suited to designs that require moderate logic capacity, on-chip RAM, and a high I/O count in a compact BGA footprint.

Key Features

• Logic Resources 8,320 logic elements and an equivalent of 526,000 gates to implement custom logic functions and state machines.
• Embedded Memory Approximately 0.106 Mbits (106,496 bits) of on-chip RAM for buffering, small data structures, and lookup tables.
• I/O Capacity 277 I/O pins to support a wide range of external interfaces and signal routing on the PCB.
• Package & Mounting 356-LBGA (35 × 35) package, surface-mount mounting type for compact board-level integration.
• Power Supply Designed to operate from a 2.375 V to 2.625 V supply range for core power.
• Temperature & Grade Commercial grade with an operating temperature range of 0°C to 85°C.
• Environmental Compliance RoHS compliant to meet common environmental and material requirements.

Unique Advantages

• High logic integration: 8,320 logic elements and 526,000 gates reduce the need for external discrete logic, simplifying system design.
• On‑chip RAM: Approximately 0.106 Mbits of embedded memory enables local buffering and lookup functions without immediate dependence on external memory.
• Dense I/O count: 277 I/O pins provide flexibility for connecting multiple peripherals, sensors, or parallel interfaces.
• Compact BGA package: 356-LBGA (35×35) minimizes PCB area while supporting high pin count routing.
• Controlled power requirements: Narrow core supply range (2.375 V–2.625 V) simplifies power-supply design and validation.
• Commercial operation and RoHS compliance: Commercial temperature rating (0°C–85°C) and RoHS compliance address common manufacturing and regulatory needs.

Why Choose EP20K200BC356-1?

The EP20K200BC356-1 delivers a balance of logic capacity, embedded memory, and extensive I/O in a compact 356-LBGA package, making it suitable for designs that require moderate programmable logic and dense interfacing within a commercial operating range. Its defined supply-voltage range and RoHS compliance make it straightforward to incorporate into standard production environments.

This device is appropriate for designers and procurement teams seeking a field-programmable solution from Altera that combines on-chip resources and a high I/O count in a space-efficient package.

Request a quote or submit an inquiry to receive pricing, availability, and purchasing information for the EP20K200BC356-1.
