EP2S130F1508C4
| Part Description |
Stratix® II Field Programmable Gate Array (FPGA) IC 1126 6747840 132540 1508-BBGA, FCBGA |
|---|---|
| Quantity | 137 Available (as of October 8, 2026) |
| Product Category | Field Programmable Gate Array (FPGA) |
|---|---|
| Manufacturer | Intel |
| Manufacturing Status | Obsolete |
| Manufacturer Standard Lead Time | Contact Us |
| Datasheet |
Specifications & Environmental
| Device Package | 1508-FBGA, FC (40x40) | Grade | Commercial | Operating Temperature | 0°C – 85°C | ||
|---|---|---|---|---|---|---|---|
| Package / Case | 1508-BBGA, FCBGA | Number of I/O | 1126 | Voltage | 1.15 V - 1.25 V | ||
| Mounting Method | Surface Mount | RoHS Compliance | RoHS non-compliant | REACH Compliance | REACH Unaffected | ||
| Moisture Sensitivity Level | 3 (168 Hours) | Number of LABs/CLBs | 6627 | Number of Logic Elements/Cells | 132540 | ||
| Number of Gates | N/A | ECCN | 3A001A7A | HTS Code | 8542.39.0001 | ||
| Qualification | N/A | Total RAM Bits | 6747840 |
Overview of EP2S130F1508C4 – Stratix® II Field Programmable Gate Array (FPGA), 132,540 logic elements, 1508-BBGA
The EP2S130F1508C4 is a high-density Stratix® II FPGA offered by Intel, delivering 132,540 logic elements and approximately 6.75 Mbits of embedded RAM. It combines substantial logic and memory resources with a high pin count and family-level architecture features to address complex, memory‑intensive, and high‑I/O digital designs.
Packaged in a 1508‑BBGA (1508‑FBGA, 40×40) surface‑mount package and rated for commercial operation from 0 °C to 85 °C, this device operates from a core supply of 1.15 V to 1.25 V and is RoHS compliant.
Key Features
- Core Logic 132,540 logic elements provide substantial programmable logic capacity for complex digital functions and system integration.
- Embedded Memory Approximately 6.75 Mbits of on‑chip RAM (triMatrix memory architecture referenced in the Stratix II family handbook) to support data buffering, FIFOs, and memory‑centric algorithms.
- I/O Capacity 1,126 user I/O pins support designs that require large numbers of external interfaces or parallel connections.
- Clocking and DSP Stratix II family features include advanced PLLs, hierarchical clocking, and dedicated digital signal processing blocks for deterministic clock management and DSP acceleration.
- Configuration & Test Family documentation highlights IEEE 1149.1 JTAG boundary‑scan support and embedded logic analyzer capability for in‑system debug and configuration flexibility.
- Power and Supply Core supply range of 1.15 V to 1.25 V offers defined operating conditions for power budgeting and supply design.
- Package & Mounting 1508‑BBGA (1508‑FBGA, FC 40×40) surface‑mount package suitable for compact, high‑density board layouts.
- Commercial Temperature Grade Specified for operation from 0 °C to 85 °C to meet standard commercial deployment requirements.
- Standards and Reliability Features Stratix II family documentation references on‑chip termination, multiple I/O standards, hot‑socketing support, and power‑on reset circuitry for robust system behavior.
Typical Applications
- High‑density digital systems — Implements complex logic and control functions where large programmable fabric is required.
- Memory‑intensive processing — Embedded RAM supports buffering, packet processing, and dataflow applications that need significant on‑chip storage.
- High‑I/O interface designs — Large I/O count enables multi‑lane parallel interfaces, dense sensor arrays, and extensive peripheral connectivity.
- Signal processing and timing‑sensitive designs — Dedicated DSP blocks and advanced PLL/clock network features in the Stratix II family support DSP workloads and precise clock distribution.
Unique Advantages
- High logic capacity: 132,540 logic elements allow consolidation of large functions onto a single device, reducing system complexity and part count.
- Substantial embedded memory: Approximately 6.75 Mbits of on‑chip RAM minimizes external memory dependence and improves data throughput.
- Extensive I/O resources: 1,126 I/O pins enable broad external connectivity and flexible board partitioning.
- Family‑level system features: Stratix II architecture includes PLLs, DSP blocks, multi‑voltage I/O support, and on‑chip termination options to simplify design implementation.
- Commercial readiness and RoHS compliant: Commercial temperature rating (0 °C to 85 °C) and RoHS compliance support mainstream product deployments.
- Compact, manufacturable package: 1508‑BBGA surface‑mount package offers a balance of density and board‑level integration for space‑constrained designs.
Why Choose EP2S130F1508C4?
The EP2S130F1508C4 positions itself as a high‑capacity Stratix II FPGA tailored for designs requiring a large programmable fabric, significant embedded memory, and a high count of I/O. Its combination of 132,540 logic elements, approximately 6.75 Mbits of on‑chip RAM, and 1,126 I/Os makes it suitable for integrating complex logic, buffering, and multi‑interface functions on a single device.
Backed by Stratix II family architecture features documented for clocking, DSP, configuration, and testability, this device is a practical option for teams aiming to consolidate functionality, streamline board design, and leverage mature FPGA family capabilities within commercial temperature and power constraints.
Request a quote or submit an inquiry to receive pricing, availability, and lead‑time information for the EP2S130F1508C4.
