XC2V2000-5FFG896C

The XC2V2000-5FFG896C is a Virtex®-II field programmable gate array (FPGA) in a 896-FCBGA package intended for commercial-grade applications. It integrates a large logic capacity and embedded memory with configurable I/O, enabling high-density logic and complex system interfacing on a single surface-mount device.

This device is suitable for designs that require substantial programmable logic (24,192 logic elements) and significant on-chip RAM (approximately 1.03 Mbits), along with 624 user I/O pins and support for industry-standard memory and high-speed interfaces as described in the Virtex-II family specification.

Key Features

• Core Capacity 24,192 logic elements and an estimated 2,000,000 system gates provide dense programmable logic for complex functions and control logic.
• Embedded Memory Approximately 1.03 Mbits of on-chip RAM (total RAM bits: 1,032,192) for packet buffering, FIFOs, lookup tables and state storage. The Virtex-II family includes 18-Kb block SelectRAM resources for block RAM implementations.
• Arithmetic Resources Dedicated multiplier resources (18-bit × 18-bit multipliers are part of the Virtex-II feature set) to accelerate DSP and arithmetic-heavy operations.
• Clock Management Digital Clock Manager (DCM) functionality is included in the Virtex-II architecture for precise clock de-skew, frequency synthesis and phase shifting.
• I/O and Interfaces 624 user I/Os with support for a broad range of I/O standards in the Virtex-II family, enabling flexible connectivity to external memories and high-speed interfaces.
• Package & Mounting 896-BBGA (FCBGA) surface-mount package, supplier device package 896-FCBGA (31 × 31 mm), suitable for compact, high-density board designs.
• Power & Supply Core voltage range specified at 1.425 V to 1.575 V for predictable power integration and system design.
• Operating Conditions Commercial grade device with operating temperature range 0 °C to 85 °C.
• Family-Level System Features Virtex-II platform highlights (from datasheet): platform FPGA architecture with SelectRAM memory hierarchy, up to 12 DCM modules, global clock multiplexer buffers, and high-performance routing and interconnect technologies.

Typical Applications

• Communications & Networking High-density logic and ample I/O make the device suitable for protocol processing, packet handling and memory interface control in network equipment.
• Embedded Systems Use as a customizable control and interface hub where programmable logic, embedded memory and multiplier resources accelerate application-specific functions.
• High-Speed Memory Interfaces Integration in systems that require sophisticated DRAM/SRAM interfaces and customizable timing control, leveraging the Virtex-II memory and I/O capabilities.
• Signal Processing DSP blocks and embedded multipliers enable offloading arithmetic-intensive tasks such as filtering, transforms and data aggregation.

Unique Advantages

• High Logic Density: 24,192 logic elements and 2,000,000 gates allow consolidation of multiple functions into a single FPGA, reducing board-level complexity.
• Significant On-Chip Memory: Approximately 1.03 Mbits of embedded RAM supports buffering and local storage to improve data throughput and reduce external memory dependence.
• Flexible I/O Count: 624 user I/Os in a 896-FCBGA package provide extensive external connectivity options for peripherals and memory devices.
• Predictable Power and Thermal Envelope: Defined core voltage range (1.425 V–1.575 V) and commercial operating temperature range (0 °C–85 °C) simplify system power and thermal planning.
• Platform-Level Feature Set: Virtex-II family capabilities such as DCMs, dedicated multipliers and SelectRAM resources enable designers to implement advanced timing control, arithmetic acceleration and memory hierarchies.

Why Choose XC2V2000-5FFG896C?

The XC2V2000-5FFG896C combines substantial programmable logic, embedded memory and a high I/O count in a compact 896-FCBGA package, making it well suited for commercial applications that require integration of complex logic, memory interfaces and signal processing. Its Virtex-II platform features—such as block SelectRAM resources, clock management and dedicated multipliers—provide building blocks for deterministic timing and arithmetic acceleration.

For teams designing high-density, feature-rich systems where on-chip resources and flexible interfacing reduce BOM and simplify board design, the XC2V2000-5FFG896C offers a balance of capacity and platform-level functionality backed by the Virtex-II specification.

Request a quote or submit a procurement inquiry to check availability and lead times for the XC2V2000-5FFG896C. Our team can provide pricing and additional technical documentation upon request.
