XC5VLX30T-1FFG665CES

The XC5VLX30T-1FFG665CES is a Virtex®-5 LXT field programmable gate array (FPGA) manufactured by AMD. It provides a combination of on-chip logic capacity, embedded memory, and high I/O count in a surface-mount FCBGA package for commercial-grade designs.

This device is suited to designs that require substantial programmable logic (30,720 logic elements), significant embedded memory (approximately 1.33 Mbits), and up to 360 user I/O lines, while operating within a 0.95–1.05 V core supply range and a commercial temperature window.

Key Features

• Core Capacity  2,400 logic blocks and 30,720 logic elements provide programmable resources for complex digital designs.
• Embedded Memory  Approximately 1.33 Mbits of on-chip RAM to support buffering, state machines, and local data storage.
• I/O  Up to 360 user I/O pins to support dense interfacing and multiple peripheral connections.
• Power  Core voltage supply range of 0.95–1.05 V to meet system power requirements.
• Package & Mounting  665-ball FCBGA package (665-BBGA, supplier package: 665-FCBGA (27×27)), surface-mount mounting for compact board integration.
• Operating Conditions & Grade  Commercial grade with an operating temperature range of 0 °C to 85 °C.
• Environmental Compliance  RoHS compliant.

Typical Applications

• High-density I/O systems  Ideal for applications that require many parallel interfaces or signal lines, leveraging the 360 available I/O connections.
• Memory-aware processing  Suitable for designs needing local buffering and fast on-chip storage thanks to approximately 1.33 Mbits of embedded RAM.
• Custom digital logic and prototyping  Provides a substantial logic element count (30,720) for implementing custom accelerators, protocol engines, or complex control logic.

Unique Advantages

• Substantial programmable logic: 30,720 logic elements support complex, integrated digital functions without external ASIC development.
• Generous on-chip memory: Approximately 1.33 Mbits of RAM reduces dependence on external memory for many buffering and stateful tasks.
• High I/O density: 360 I/O pins enable broad interfacing options for sensors, peripherals, and multi-channel data paths.
• Compact, surface-mount FCBGA: 665-ball FCBGA (27×27) package balances high resource density with a compact board footprint.
• Defined commercial operating range: Operates across 0 °C to 85 °C and is RoHS compliant for standard commercial applications.
• Controlled core power window: 0.95–1.05 V supply range aligns with expected system power rails for the device.

Why Choose XC5VLX30T-1FFG665CES?

Designed by AMD, the XC5VLX30T-1FFG665CES delivers a balanced combination of logic capacity, embedded memory, and high I/O count in a compact FCBGA package for commercial embedded designs. Its specifications make it a practical choice for teams implementing complex digital functions, prototyping advanced logic, or integrating multiple high-density interfaces on a single board.

For engineering and procurement teams looking for a commercial-grade FPGA with clear on-chip resources and defined operating parameters, this Virtex®-5 LXT device offers predictable integration and deployment characteristics backed by AMD manufacturing.

Request a quote or submit an inquiry to our sales team to check availability and pricing for XC5VLX30T-1FFG665CES.
