XC7A100T-L2FGG484E

The XC7A100T-L2FGG484E is an Artix-7 Field Programmable Gate Array (FPGA) IC designed for surface-mount applications. It combines high logic capacity, substantial on-chip memory, and a large I/O count in a compact 484-BBGA package.

Key device attributes include 7,925 CLBs (101,440 logic elements), approximately 4.98 Mbits of embedded memory, 285 user I/O pins, an extended-grade operating range, and a core supply window of 950 mV to 1.05 V—properties that support complex programmable digital designs requiring dense logic and local RAM.

Key Features

• Core Logic  7,925 CLBs providing 101,440 logic elements for implementing complex digital logic and custom processing pipelines.
• Embedded Memory  Approximately 4.98 Mbits of total on-chip RAM bits to support buffering, frame storage, and local data processing.
• I/O Capacity  285 user I/O pins to interface with wide parallel buses, multiple peripherals, or mixed-signal front-ends.
• Package and Mounting  484-BBGA package in a surface-mount form factor (supplier device package: 484-FBGA, 23×23) for compact, high-density board layouts.
• Power  Core voltage support range of 950 mV to 1.05 V to match system power rails and design constraints.
• Thermal and Grade  Extended grade operation with an operating temperature range of 0 °C to 100 °C for deployment in temperature-controlled environments.
• Regulatory  RoHS compliant, supporting product-level environmental and materials requirements.

Typical Applications

• Programmable Logic Prototyping  Use the device’s 101,440 logic elements and approximately 4.98 Mbits of embedded memory for validating complex digital designs and custom IP implementations.
• High-Density I/O Systems  With 285 I/O pins, the FPGA is suitable for designs that require extensive peripheral or bus interfacing on a single device.
• Embedded Data Processing  Local on-chip RAM and abundant logic resources enable buffering, preprocessing, and custom data-path implementations within embedded systems.

Unique Advantages

• High Logic Density: 101,440 logic elements and 7,925 CLBs allow consolidation of multiple functions onto a single FPGA, reducing system BOM and board complexity.
• Substantial On-Chip Memory: Approximately 4.98 Mbits of embedded RAM minimizes external memory dependence for many buffering and streaming tasks.
• Large I/O Count: 285 user I/O pins provide flexibility to connect numerous peripherals, sensor arrays, or parallel interfaces without additional I/O expanders.
• Compact Surface-Mount Package: The 484-BBGA (supplier: 484-FBGA, 23×23) package enables space-efficient board designs while supporting high pin counts.
• Controlled Power Envelope: Core supply range of 950 mV to 1.05 V supports designs targeting low-voltage FPGA core operation.
• Extended-Grade Operation: Rated for 0 °C to 100 °C operation to meet requirements for temperature-controlled or commercial environments.

Why Choose XC7A100T-L2FGG484E?

The XC7A100T-L2FGG484E is positioned for designs requiring a balance of high logic capacity, embedded memory, and abundant I/O in a compact surface-mount package. Its combination of 101,440 logic elements, approximately 4.98 Mbits of on-chip RAM, and 285 I/Os makes it suitable for consolidating multi-function digital subsystems and reducing external components.

Designed as an extended-grade, RoHS-compliant device with a defined core voltage window, this Artix-7 FPGA offers predictable integration for teams focused on scalable, densely packed programmable logic implementations and efficient board-level layouts.

Request a quote or submit a purchase inquiry to obtain pricing and availability for XC7A100T-L2FGG484E.
