EP20K1000CB652C9ES
| Part Description |
APEX-20KC® Field Programmable Gate Array (FPGA) IC 488 327680 38400 652-BGA |
|---|---|
| Quantity | 647 Available (as of May 5, 2026) |
| Product Category | Field Programmable Gate Array (FPGA) |
|---|---|
| Manufacturer | Intel |
| Manufacturing Status | Obsolete |
| Manufacturer Standard Lead Time | RFQ |
| Datasheet |
Specifications & Environmental
| Device Package | 652-BGA (45x45) | Grade | Commercial | Operating Temperature | 0°C – 85°C | ||
|---|---|---|---|---|---|---|---|
| Package / Case | 652-BGA | Number of I/O | 488 | Voltage | 1.71 V - 1.89 V | ||
| Mounting Method | Surface Mount | RoHS Compliance | Unknown | REACH Compliance | REACH Unknown | ||
| Moisture Sensitivity Level | 3 (168 Hours) | Number of LABs/CLBs | 3840 | Number of Logic Elements/Cells | 38400 | ||
| Number of Gates | 1772000 | ECCN | OBSOLETE | HTS Code | 0000.00.0000 | ||
| Qualification | N/A | Total RAM Bits | 327680 |
Overview of EP20K1000CB652C9ES – APEX-20KC Field Programmable Gate Array, 652-BGA
The EP20K1000CB652C9ES is an APEX-20KC series FPGA in a 652-BGA (45×45) package delivering high-density, reprogrammable logic and on-chip memory for commercial embedded systems. The device combines a MultiCore architecture with LUT-based logic and embedded system blocks (ESBs) to implement memory-intensive functions while preserving logic resources.
Designed for applications that require significant logic capacity and flexible I/O, this device provides 38,400 logic elements, approximately 0.33 Mbits of embedded RAM, and 488 user I/O pins in a surface-mount BGA package.
Key Features
- Core Architecture The MultiCore architecture with LUT logic supports register-intensive functions and high-density combinational logic.
- Logic Density 38,400 logic elements and approximately 1,772,000 gates provide substantial programmable logic resources for complex designs.
- On-chip Memory Approximately 327,680 bits of embedded RAM (about 0.33 Mbits) and multiple ESBs for FIFO, dual-port RAM, and CAM implementations.
- Clocking and PLLs Flexible clock management with support for up to four phase-locked loops (PLLs), multiple global clocks, and programmable clock-shift and multiplication/division features (series-level capability).
- I/O and Interfaces 488 user I/O pins with MultiVolt I/O support and advanced signaling options noted for the series, including differential and legacy interfaces (series-level capability).
- Performance and Interconnect Copper interconnect and a hierarchical FastTrack interconnect structure for predictable, low-delay routing; dedicated carry and cascade chains for arithmetic and high-fan-in logic.
- Power and Voltage Internal/core voltage around 1.8 V with a listed supply range of 1.71 V to 1.89 V; ESBs include programmable power-saving modes at the series level.
- Package & Temperature 652-BGA (45×45) surface-mount package; commercial grade with an operating temperature range of 0 °C to 85 °C.
- Regulatory RoHS compliant.
Typical Applications
- High-speed memory interfaces Implement DDR SDRAM and ZBT SRAM controllers using on-chip RAM and dedicated I/O support.
- Bus bridging and peripheral interfaces Support for PCI-class interfaces and flexible I/O makes the device suitable for custom bus logic and protocol bridging.
- Data acquisition and LVDS links Series-level support for multiple LVDS channels enables high-speed serial/parallel data capture and transmission.
- Embedded system controllers Use the combination of logic elements and ESBs to implement control, buffering, and specialized memory functions within embedded products.
Unique Advantages
- High programmable capacity: 38,400 logic elements and roughly 1.77 million gates provide room for complex logic integration without external ASICs.
- Significant embedded memory: Approximately 0.33 Mbits of on-chip RAM and multiple ESBs let you implement FIFOs and dual-port RAM while preserving logic resources.
- Flexible clocking: Up to four PLLs and multiple global clocks enable precise timing control and clock domain management for high-performance designs.
- Robust I/O options: 488 user I/O pins and series-level multi-voltage I/O support accommodate a wide range of external devices and memory interfaces.
- Compact, surface-mount package: The 652-BGA (45×45) package provides a dense footprint for space-constrained boards while supporting high pin counts.
- Compliance and manufacturability: RoHS compliance and standard commercial temperature grading ease integration into mainstream production lines.
Why Choose EP20K1000CB652C9ES?
The EP20K1000CB652C9ES positions itself as a high-density, commercially graded FPGA choice for teams needing a balance of logic capacity, on-chip memory, and flexible I/O in a compact BGA package. Its MultiCore architecture, dedicated arithmetic and cascade chains, and embedded system blocks support memory-centric and register-intensive designs while helping to keep system BOM complexity under control.
This device is well suited to engineers and procurement teams building mid- to high-complexity embedded systems that require scalable logic, on-chip buffering, and versatile interface support, backed by the APEX-20KC series feature set and RoHS compliance.
Request a quote or submit an inquiry for pricing and availability for the EP20K1000CB652C9ES to move your design forward.
