EP2AGX45CU17I5N

The EP2AGX45CU17I5N is an Arria II GX FPGA in a 358-LFBGA (17×17) FCBGA package designed for industrial-grade applications. It provides a programmable logic fabric, embedded memory, and I/O resources for system integration where deterministic control of logic and interfaces is required.

Documented in the Arria II Device Handbook, the device family includes detailed electrical characteristics and transceiver performance specifications to support designs requiring defined core supply ranges and industrial operating conditions.

Key Features

• Programmable Logic — 42,959 logic elements suitable for implementing custom digital logic, control, and processing functions.
• Embedded Memory — Approximately 3.5 Mbits of on-chip RAM to support buffering, packet handling, and intermediate data storage within the FPGA fabric.
• I/O Resources — 156 user I/Os for flexible interfacing to peripherals, sensors, and external devices.
• Package and Mounting — 358-LFBGA, FCBGA (358-UBGA, 17×17) surface-mount package for compact board-level integration.
• Industrial Temperature Range — Specified operating range from −40 °C to 100 °C for use in temperature-challenging environments.
• Core Supply Voltage — Core voltage range of 870 mV to 930 mV, consistent with the device electrical specifications in the device handbook.
• Regulatory Compliance — RoHS compliant.
• Device Documentation — Covered by the Arria II Device Handbook, which includes electrical characteristics, transceiver performance specifications, and I/O timing details.

Typical Applications

• Industrial Control — Deterministic logic and I/O count for machine control, automation interfaces, and process monitoring within industrial temperature ranges.
• High-speed I/O and Communications — Device handbook includes transceiver performance and PCI Express (PIPE) block references, supporting designs that require defined high-speed interface behavior.
• Embedded System Integration — On-chip RAM and abundant logic elements enable integration of custom preprocessing, protocol handling, and glue logic to reduce external component count.

Unique Advantages

• Significant Logic Capacity: 42,959 logic elements provide headroom for complex logic, custom accelerators, and state machines.
• Integrated Embedded Memory: Approximately 3.5 Mbits of on-chip RAM reduces dependence on external memory for buffering and intermediate data storage.
• Robust Operating Range: Industrial-grade temperature specification (−40 °C to 100 °C) supports deployment in harsher environments.
• Compact, Board-Ready Package: 358-LFBGA/UBGA (17×17) surface-mount package enables dense integration on modern PCBs.
• Defined Core Power Envelope: Core supply range of 870 mV–930 mV aligns with the device electrical requirements documented in the Arria II handbook.
• Standards-Aligned Documentation: Comprehensive device handbook coverage of electrical and transceiver characteristics supports design verification and system-level planning.

Why Choose EP2AGX45CU17I5N?

The EP2AGX45CU17I5N delivers a balanced combination of programmable logic, embedded memory, and I/O count in an industrial-grade Arria II GX device. Its documented electrical characteristics and transceiver sections in the device handbook help engineers manage power, timing, and interface behavior during system design.

This part is well suited for designers who need a compact, surface-mount FPGA platform with substantial logic and memory resources, predictable core supply requirements, and an operating temperature range appropriate for industrial deployments.

Request a quote or submit an inquiry for EP2AGX45CU17I5N to receive pricing, availability, and ordering information.
