EP3SL70F780C3N
| Part Description |
Stratix® III L Field Programmable Gate Array (FPGA) IC 488 2699264 67500 780-BBGA, FCBGA |
|---|---|
| Quantity | 895 Available (as of October 8, 2026) |
| Product Category | Field Programmable Gate Array (FPGA) |
|---|---|
| Manufacturer | Intel |
| Manufacturing Status | Obsolete |
| Manufacturer Standard Lead Time | Contact Us |
| Datasheet |
Specifications & Environmental
| Device Package | 780-FBGA (29x29) | Grade | Commercial | Operating Temperature | 0°C – 85°C | ||
|---|---|---|---|---|---|---|---|
| Package / Case | 780-BBGA, FCBGA | Number of I/O | 488 | Voltage | 860 mV - 1.15 V | ||
| Mounting Method | Surface Mount | RoHS Compliance | RoHS Compliant | REACH Compliance | REACH Unknown | ||
| Moisture Sensitivity Level | 3 (168 Hours) | Number of LABs/CLBs | 2700 | Number of Logic Elements/Cells | 67500 | ||
| Number of Gates | N/A | ECCN | 3A991D | HTS Code | 8542.39.0001 | ||
| Qualification | N/A | Total RAM Bits | 2699264 |
Overview of EP3SL70F780C3N – Stratix® III L FPGA, 67,500 logic elements, 488 I/O (780-FBGA)
The EP3SL70F780C3N is a Stratix® III L Field Programmable Gate Array (FPGA) manufactured by Intel. It combines a large logic fabric with on-chip embedded memory and flexible I/O to implement complex, custom digital functions.
Designed for commercial-grade applications, the device offers 67,500 logic elements, approximately 2.7 Mbits of embedded memory, and 488 general-purpose I/O in a 780-ball FCBGA package. Key value propositions include substantial integration density, a broad I/O complement, and architecture-level features documented in the Stratix III Device Handbook.
Key Features
- Core Logic 67,500 logic elements provide capacity for complex combinational and sequential logic implementation.
- Embedded Memory Approximately 2.7 Mbits of on-chip RAM support data buffering, FIFOs, and local storage for implemented functions.
- I/O Resources 488 I/O pins enable extensive external connectivity and interfacing to peripherals and external memories.
- Device Architecture (as documented) Stratix III architectural elements referenced in the device handbook include TriMatrix embedded memory blocks, DSP blocks, multi-track interconnect, clock networks and PLLs, and high-speed differential I/O support with DPA.
- System and Configuration Device handbook topics include configuration options, IEEE 1149.1 (JTAG) boundary-scan testing, design security, SEU mitigation, and programmable power features.
- Package & Mounting 780-BBGA (FCBGA) supplier device package, 29 × 29 mm, surface-mount mounting type for compact board-level integration.
- Electrical & Environmental Core supply voltage range 0.860 V to 1.15 V; commercial operating temperature range 0 °C to 85 °C. RoHS compliant.
Typical Applications
- High-bandwidth external memory interfaces 488 I/O and the device’s embedded memory resources support designs that require external memory controllers and wide memory buses.
- Signal processing and DSP functions Architecturally supported DSP blocks and a large logic element count enable implementation of custom signal-processing pipelines and accelerators.
- Complex glue-logic and protocol bridging The combination of extensive I/O and abundant logic capacity suits applications that consolidate multiple peripheral interfaces or implement protocol translation.
- Prototype and system integration platforms The FCBGA package and surface-mount footprint allow integration into development and system-level boards for validating large-scale FPGA designs.
Unique Advantages
- Substantial logic capacity: 67,500 logic elements provide headroom for complex finite-state machines, custom datapaths, and hardware accelerators.
- On-chip memory for local buffering: Approximately 2.7 Mbits of embedded RAM reduce dependence on external memory for intermediate data storage.
- Extensive I/O flexibility: 488 I/O pins support broad external connectivity, enabling multi-channel interfaces and wide buses without extensive multiplexing.
- Documented architecture and system features: The Stratix III Device Handbook details memory blocks, DSP blocks, clocking resources, configuration and test support, aiding system-level design and verification.
- Compact production package: 780-BBGA (29 × 29 mm) surface-mount package balances pin count and board-area efficiency for commercial applications.
- Commercial-grade and compliant: Rated for 0 °C to 85 °C operation and RoHS compliant for standard commercial deployments.
Why Choose EP3SL70F780C3N?
The EP3SL70F780C3N positions itself as a high-capacity Stratix III L FPGA suited for commercial designs that require substantial logic density, meaningful on-chip memory, and a large I/O complement. Its documented architecture elements—memory blocks, DSP resources, clocking, and configuration/test features—support implementation of sophisticated digital systems while simplifying integration at the board level.
This device is ideal for engineering teams building complex protocol bridges, signal-processing accelerators, memory interface controllers, or prototype platforms where integration density and I/O flexibility are priorities. Its commercial temperature rating and RoHS compliance support production deployments within standard commercial environments.
Request a quote or submit a sales inquiry to receive pricing, availability, and ordering information for EP3SL70F780C3N.
