EPF6024AFC256-2AA

The EPF6024AFC256-2AA is a FLEX 6000 family Field Programmable Gate Array (FPGA) manufactured by Altera. It provides a mid-range programmable logic solution with a defined logic element capacity and a high I/O count for integration into a variety of electronic designs.

This device targets applications that require flexible, reconfigurable logic in a compact surface-mount 256-FBGA (17×17) package, operating from a 3.0 V to 3.6 V supply and within a commercial temperature range of 0 °C to 85 °C. RoHS compliance supports use in standard commercial product assemblies.

Key Features

• Logic Capacity  Approximately 1,960 logic elements and around 24,000 equivalent gates provide mid-range programmable logic resources for custom functions and glue-logic integration.
• I/O Density  219 I/O pins enable connectivity to multiple peripherals, interfaces, and system buses without external expansion.
• Package and Mounting  256-ball FBGA (256-FBGA, 17×17) in a surface-mount package offers a compact footprint suited to space-constrained boards.
• Power  Single-supply operation from 3.0 V to 3.6 V simplifies power-rail planning in standard commercial designs.
• Operating Range  Commercial temperature rating from 0 °C to 85 °C for typical consumer and commercial applications.
• Compliance  RoHS-compliant construction for regulatory alignment in commercial product manufacturing.

Typical Applications

• Consumer Electronics  Implements custom control logic, signal routing, and peripheral interfacing in compact consumer devices.
• Communications Equipment  Provides reconfigurable logic and high I/O capability for protocol glue logic and peripheral management.
• Prototyping and Development  Supports rapid iteration of custom logic and system-level validation on development boards and evaluation platforms.
• Test and Measurement  Enables bespoke data handling, timing control, and interface adaptation in laboratory and benchtop instruments.

Unique Advantages

• Balanced Logic Density:  Approximately 1,960 logic elements deliver a mid-range resource set suitable for implementing complex glue logic and moderate-size custom functions without excessive board-level components.
• High Pin Count in Compact Footprint:  219 I/Os in a 256-FBGA (17×17) package allow broad external connectivity while preserving board area.
• Simple Power Integration:  3.0 V to 3.6 V supply range aligns with common commercial power rails for straightforward system integration.
• Commercial Temperature Suitability:  Rated 0 °C to 85 °C to meet the environmental expectations of typical commercial and consumer products.
• RoHS Compliance:  Manufactured to RoHS standards to support environmentally compliant product builds.

Why Choose EPF6024AFC256-2AA?

The EPF6024AFC256-2AA is positioned as a versatile, mid-range FPGA choice for designers needing reconfigurable logic with substantial I/O capacity in a compact BGA package. Its balance of logic elements, gate count, and high pin count makes it suitable for consumer, communications, and test applications where board space and connectivity are important considerations.

With standard commercial operating limits, single-supply voltage compatibility, and RoHS compliance, this Altera FLEX 6000 device provides a predictable platform for development and production designs that require reliable, reprogrammable logic in a surface-mount form factor.
