XA2S100E-6TQ144Q

The XA2S100E-6TQ144Q is a Spartan®-IIE XA field programmable gate array (FPGA) offering a mid-range balance of programmable logic capacity and I/O count in a compact 144-LQFP package. With 2,700 logic elements, 600 CLBs and 40,960 bits of on-chip RAM, it targets embedded and automotive applications that require reconfigurable logic, significant I/O and reliable operation across an extended temperature range.

Designed for surface-mount assembly and qualified to AEC-Q100, this device provides automotive-grade qualification alongside RoHS compliance and a low-voltage supply range for power-sensitive designs.

Key Features

• Core & Logic  2,700 logic elements and 600 CLBs provide the programmable logic resources necessary for combinational and sequential logic implementation; the device is rated at 100,000 gates.
• Embedded Memory  40,960 bits of on-chip RAM for buffering, small lookup tables and state storage without external memory.
• I/O Capacity  102 general-purpose I/O pins enable connectivity to sensors, peripherals and external logic devices.
• Power  Operates from a core voltage supply range of 1.71 V to 1.89 V to support power-constrained system designs.
• Package & Mounting  Supplied in a 144-LQFP (supplier package 144-TQFP, 20×20 mm) with surface-mount mounting for common PCB assembly flows.
• Automotive Qualification  Grade: Automotive and qualification per AEC-Q100 for designs that require automotive-grade components.
• Temperature Range  Rated for operation from −40 °C to 125 °C to meet wide-temperature application requirements.
• Regulatory Compliance  RoHS compliant for environmentally responsible designs.

Typical Applications

• Automotive Electronics  Programmable logic for vehicle subsystems that leverage AEC-Q100 qualification and a −40 °C to 125 °C operating range.
• Embedded Control Systems  Implement control logic, state machines and peripheral interfacing using 2,700 logic elements and 102 I/Os.
• Sensor and I/O Aggregation  Aggregate, buffer and pre-process sensor signals or digital peripherals using on-chip RAM and ample I/O.
• Prototyping and Custom Logic  Rapidly validate custom logic functions and integrations in a compact, surface-mount FPGA package.

Unique Advantages

• Automotive-Grade Qualification: AEC-Q100 qualification and automotive grade designation provide confidence for vehicle-level designs and systems that require qualified components.
• Balanced Logic and I/O: 2,700 logic elements paired with 102 I/Os support moderately complex designs with significant external interfacing needs, reducing the need for additional glue logic.
• On-Chip Memory: 40,960 bits of embedded RAM enable local buffering and state retention without immediate reliance on external memory devices.
• Wide Operating Temperature: −40 °C to 125 °C rating supports deployments across harsh thermal environments.
• Compact, SMT-Friendly Package: 144-LQFP surface-mount package simplifies PCB integration while maintaining sufficient pin count for diverse I/O usage.
• RoHS Compliance: Environmentally compliant manufacturing support for regulatory and sustainability objectives.

Why Choose XA2S100E-6TQ144Q?

The XA2S100E-6TQ144Q positions itself as a reliable, automotive-grade FPGA offering a practical mix of logic capacity, on-chip memory and I/O in a compact 144-LQFP package. Its AEC-Q100 qualification and extended temperature range make it suitable for applications that demand robust operation across challenging environmental conditions.

This device is well suited for engineers and procurement teams seeking a mid-range programmable logic solution that balances integration, thermal robustness and compliance for embedded and automotive projects requiring reconfigurable logic and significant I/O connectivity.

Request a quote or submit an inquiry for pricing and availability of XA2S100E-6TQ144Q to move your design forward.
