XA3S200-4PQG208I

The XA3S200-4PQG208I is a Spartan®-3 XA Field Programmable Gate Array from AMD, providing a balanced combination of logic resources, on-chip memory, and I/O density in a compact surface-mount package. Its specification set supports applications that require moderate logic capacity, embedded RAM, and a rugged operating range.

This device is AEC‑Q100 qualified for automotive use and operates across a wide temperature range, making it suitable for automotive electronic subsystems and other embedded systems that demand reliable low-voltage FPGA integration.

Key Features

• Core Logic  Approximately 4,320 logic elements (cells) and around 200,000 gates provide the programmable fabric for implementing custom logic and finite-state designs.
• Embedded Memory  Total on-chip RAM of 221,184 bits (approximately 0.22 Mbits) supports buffering, small data tables, and local storage for control logic.
• I/O Capacity  Up to 141 user I/O pins to interface with sensors, actuators, peripherals and board-level signals.
• Power  Low-voltage supply range from 1.14 V to 1.26 V for core operation.
• Automotive Qualification & Temperature  AEC‑Q100 qualification and specified operating temperature range of −40 °C to 100 °C for automotive-grade deployments.
• Package & Mounting  Surface-mount 208‑BFQFP package (supplier device package: 208‑PQFP, 28×28) for compact PCB integration.
• Regulatory  RoHS compliant.

Typical Applications

• Automotive electronic subsystems  AEC‑Q100 qualification and a −40 °C to 100 °C operating range make this FPGA suitable for vehicle control modules and subsystems requiring programmable logic.
• Embedded control and signal processing  Moderate logic capacity and on-chip RAM support control algorithms, state machines, and localized data processing in embedded devices.
• Board-level integration  High I/O count and a compact 208‑pin PQFP package allow designers to integrate programmable functionality into space-constrained PCBs.

Unique Advantages

• AEC‑Q100 qualified for automotive use: Enables deployment in automotive electronic designs that require qualified components.
• Compact, surface-mount package: 208‑BFQFP (208‑PQFP, 28×28) offers a board-friendly footprint for space-constrained applications.
• Balanced logic and memory resources: Around 4,320 logic elements and approximately 0.22 Mbits of embedded RAM support a wide range of moderate-complexity designs without external memory.
• Generous I/O density: 141 I/O pins facilitate multiple peripheral interfaces and sensor/actuator connections on a single device.
• Low-voltage core operation: Core supply range of 1.14 V to 1.26 V supports low-voltage system designs.
• RoHS compliant: Conforms to environmental requirements for lead-free manufacturing and assembly.

Why Choose XA3S200-4PQG208I?

The XA3S200-4PQG208I positions itself as a practical, automotive‑qualified FPGA option for designers who need a reliable, low-voltage programmable device with moderate logic density, embedded memory, and substantial I/O capability. Its AEC‑Q100 qualification and extended temperature range make it appropriate for vehicle electronics and other rugged embedded applications.

From compact PCB integration in a 208‑pin PQFP package to approximately 4,320 logic elements and 221,184 bits of on-chip RAM, this AMD Spartan‑3 XA device delivers a clear balance of integration, reliability, and predictable electrical characteristics for long-term designs.

Request a quote or submit an inquiry to obtain pricing and availability for XA3S200-4PQG208I. Include part number and required quantity to receive a prompt response.
