XC2S150-6PQ208C

The XC2S150-6PQ208C is an AMD Spartan®-II field programmable gate array (FPGA) supplied in a 208-pin BFQFP/PQFP package. This commercial-grade, surface-mount FPGA provides a mid-range balance of programmable logic, on-chip memory, and I/O density for designs that require configurable digital logic in a compact package.

Key on-chip resources include 864 CLBs (configurable logic blocks), 3,888 logic elements, approximately 49 kbits of embedded RAM, and 140 user I/O pins. The device operates from a 2.375 V to 2.625 V core supply and is specified for operation from 0 °C to 85 °C, with RoHS compliance for environmental conformity.

Key Features

• Core Logic 864 CLBs delivering 3,888 logic elements and approximately 150,000 gates, suitable for moderate-density programmable logic implementations.
• Embedded Memory Approximately 49 kbits of on-chip RAM available for buffering, state storage, and small embedded data structures.
• I/O Capacity 140 user I/O pins to support a broad set of external interfaces and parallel connections within a single device.
• Power and Supply Requires a core voltage supply in the range of 2.375 V to 2.625 V for stable operation.
• Package and Mounting 208-BFQFP package (supplier device package: 208-PQFP 28×28) with surface-mount mounting type for compact PCB integration.
• Operating Range Commercial-grade temperature rating from 0 °C to 85 °C for standard ambient operating environments.
• Environmental Compliance RoHS compliant to meet lead-free and restricted-substance requirements.

Typical Applications

• Embedded Control Systems Use the XC2S150-6PQ208C when 3,888 logic elements and 140 I/O pins are needed for custom control logic and peripheral interfacing.
• Protocol Bridging and Glue Logic Ideal for designs requiring mid-range programmable logic to implement bus bridges, signal adaptation, and custom timing logic.
• Prototyping and Development Suitable for hardware prototypes that need reconfigurable logic with on-chip RAM and a compact 208-pin PQFP footprint.

Unique Advantages

• Balanced Logic Density: 3,888 logic elements and 864 CLBs provide sufficient capacity for many mid-range FPGA tasks without the footprint of larger devices.
• Integrated Memory: Approximately 49 kbits of on-chip RAM reduces external memory requirements for small buffers and state machines.
• Generous I/O Count: 140 user I/O pins enable multiple parallel interfaces or mixed-signal front-ends on a single device.
• Compact Surface-Mount Package: 208-PQFP (28×28) packaging offers a space-efficient solution for PCB-constrained designs.
• Commercial Temperature and RoHS Compliant: Commercial-grade (0 °C to 85 °C) specification and RoHS compliance support standard production and environmental requirements.

Why Choose XC2S150-6PQ208C?

The XC2S150-6PQ208C positions itself as a practical choice for engineers who need a mid-range Spartan®-II FPGA offering a combination of logic capacity, embedded memory, and a high I/O count in a compact 208-pin PQFP package. Its commercial temperature rating and RoHS compliance make it suitable for mainstream electronics applications where configurable logic and board-level integration matter.

Manufactured by AMD, this device is part of a well-documented FPGA family and is appropriate for developers seeking a reliable, reprogrammable hardware building block for control logic, interface adaptation, and prototype systems that operate within standard commercial environments.
