XC6SLX9-L1CSG225C

The XC6SLX9-L1CSG225C is a Spartan®-6 LX field programmable gate array (FPGA) IC designed for commercial applications requiring moderate logic density and flexible I/O. It integrates logic resources, embedded RAM, and a low-voltage core in a compact 225-CSPBGA package.

This device is suited to commercial embedded systems and consumer electronics where a balance of programmable logic capacity, on-chip memory, and package density are important considerations.

Key Features

• Core Logic  9,152 logic elements and 715 CLBs for implementing custom digital logic and glue logic functions.
• Embedded Memory  Approximately 0.59 Mbits of embedded memory (589,824 total RAM bits) to support on-chip buffering and intermediate data storage.
• I/O Capacity  160 user I/Os to interface with peripherals, sensors, and external logic.
• Power  Low-voltage core operation with a supply range of 1.14 V to 1.26 V for designs targeting reduced core power consumption.
• Package & Mounting  225-LFBGA / 225-CSPBGA (13×13) supplier device package, surface-mount mounting type for compact board-level integration.
• Temperature & Grade  Commercial-grade device rated for 0 °C to 85 °C operating temperature.
• Environmental Compliance  RoHS compliant for regulatory and environmental conformity.

Typical Applications

• Consumer Electronics  Interface control and peripheral management where moderate logic and on-chip RAM simplify system design in compact packages.
• Embedded Control  Custom control logic, protocol bridging, and sequencing functions that benefit from programmable logic and flexible I/O.
• Prototyping and Evaluation  Design validation and proof-of-concept implementations that require reprogrammable logic resources and on-board memory.

Unique Advantages

• Moderate Logic Capacity: 9,152 logic elements provide ample resources for mid-density digital designs without overprovisioning.
• Integrated On-Chip RAM: Approximately 0.59 Mbits of embedded memory reduces the need for external RAM in many buffering and state-storage tasks.
• Generous I/O Count: 160 I/Os enable broad peripheral connectivity and flexible board-level interfacing.
• Compact, Surface-Mount Package: 225-CSPBGA (13×13) package supports high-density board layouts and automated assembly processes.
• Low-Voltage Core Operation: 1.14 V to 1.26 V supply range allows designs targeting lower core power consumption.
• Commercial Temperature Range: Rated 0 °C to 85 °C to match standard commercial product environments.

Why Choose XC6SLX9-L1CSG225C?

The XC6SLX9-L1CSG225C positions itself as a practical choice for designers needing a mid-range FPGA with a balanced mix of logic, embedded memory, and I/O in a compact, surface-mount package. Its 9,152 logic elements, approximately 0.59 Mbits of embedded RAM, and 160 I/Os make it suitable for commercial embedded designs and consumer applications that require programmable logic without large form-factor overhead.

With low-voltage core operation and RoHS compliance, this Spartan®-6 LX device provides a compact, standards-aligned building block for production systems where moderate programmable capacity and board-level density matter.
