XC7VX690T-2FF1761C

The XC7VX690T-2FF1761C is a Virtex®-7 XT Field Programmable Gate Array (FPGA) designed for applications that require a large logic capacity and extensive I/O. Its architecture provides a high count of logic elements and substantial on-chip RAM, making it suitable for complex, configurable digital designs.

This device is offered in a 1760-BBGA FCBGA package with surface-mount mounting and is specified for commercial-grade operation between 0 °C and 85 °C. It is RoHS compliant and operates with a core supply range of 970 mV to 1.03 V.

Key Features

• Logic Capacity — Provides 693,120 logic elements to implement large, highly parallel digital designs and complex custom logic.
• Embedded Memory — Approximately 54 Mbits of on-chip RAM (54,190,080 bits) for frame buffers, FIFOs, and data staging without external memory dependency.
• I/O Density — 850 user I/O pins to support wide bus interfaces, multi-lane links, and numerous peripheral connections.
• Power and Core Supply — Core voltage specified from 970 mV to 1.03 V to match system power rails and ensure correct device operation within the defined range.
• Package and Mounting — 1760-BBGA FCBGA package, supplier device package 1761-FCBGA (42.5×42.5), designed for surface-mount assembly in space-constrained board layouts.
• Operating Range and Grade — Commercial-grade device rated for 0 °C to 85 °C operation.
• Environmental Compliance — RoHS compliant.

Typical Applications

• Data processing and acceleration: Large logic capacity and on-chip RAM enable custom compute pipelines and data staging for algorithm acceleration.
• High-density I/O systems: With 850 I/O pins, the device supports multi-interface integration and complex board-level interconnects.
• Prototyping and system integration: Flexible FPGA fabric and significant embedded memory support development and validation of complex digital subsystems.

Unique Advantages

• Substantial logic resources: 693,120 logic elements allow implementation of large-scale custom logic and parallel processing architectures.
• On-chip memory capacity: Approximately 54 Mbits of embedded RAM reduces reliance on external memory and simplifies board design.
• High I/O count: 850 I/O pins provide design flexibility for interfacing multiple peripherals, buses, and high-bandwidth links.
• Commercial-temperature rating: Specified operation from 0 °C to 85 °C for typical commercial applications.
• Surface-mount FCBGA packaging: 1760-BBGA package and 1761-FCBGA supplier package footprint (42.5×42.5) support compact, high-density PCB layouts.
• Regulatory compliance: RoHS compliance supports environmentally conscious product designs.

Why Choose XC7VX690T-2FF1761C?

The XC7VX690T-2FF1761C combines a very large logic element count with substantial on-chip RAM and a high I/O pin count to address designs that demand significant programmable logic and memory integration. Its FCBGA package and surface-mount form factor enable compact system integration while the specified core voltage range and commercial-temperature rating define clear system-level power and thermal requirements.

This device is well suited for engineering teams building complex digital subsystems that require scalability, extensive I/O connectivity, and embedded memory for data buffering and temporary storage. The Virtex®-7 family heritage and RoHS compliance provide an established platform for long-term development and deployment in commercial applications.

Request a quote or submit a procurement request to obtain pricing, lead-time, and availability for the XC7VX690T-2FF1761C.
