XCV50-6BG256C

IC FPGA 180 I/O 256BGA
Part Description

Virtex® Field Programmable Gate Array (FPGA) IC 180 32768 1728 256-BBGA

Quantity 149 Available (as of October 8, 2026)
Product CategoryField Programmable Gate Array (FPGA)
ManufacturerAMD
Manufacturing StatusObsolete
Manufacturer Standard Lead TimeContact Us
Datasheet

Specifications & Environmental

Device Package256-PBGA (27x27)GradeCommercialOperating Temperature0°C – 85°C
Package / Case256-BBGANumber of I/O180Voltage2.375 V - 2.625 V
Mounting MethodSurface MountRoHS ComplianceRoHS non-compliantREACH ComplianceREACH Unaffected
Moisture Sensitivity Level3 (168 Hours)Number of LABs/CLBs384Number of Logic Elements/Cells1728
Number of Gates57906ECCNEAR99HTS Code8542.39.0001
QualificationN/ATotal RAM Bits32768

Overview of XCV50-6BG256C – Virtex Field Programmable Gate Array, 256-BBGA

The XCV50-6BG256C is an SRAM-based Virtex FPGA offering programmable logic and embedded memory in a 256-ball BGA package. It combines configurable logic elements, on-chip RAM, and multi-standard I/O capability for demanding embedded and interface-centric applications.

Targeted at designs that require flexible in-system reconfiguration and a balance of performance and integration, this device supports up to 180 I/O pins and provides 32,768 bits of embedded block RAM for data buffering, protocol handling, and control logic.

Key Features

  • Core logic — 1,728 logic elements (≈57,906 system gates) provide programmable combinational and sequential resources for custom digital functions.
  • On-chip memory — 32,768 bits of block RAM for FIFOs, buffering, and small data stores; LUTs can be configured as various small SRAM structures per device architecture.
  • I/O and interface support — Up to 180 user I/O pins with multi-standard SelectIO support (16 high‑performance interface standards) for flexible interface implementation.
  • Clock management — Built-in clock-management circuitry with four dedicated delay-locked loops (DLLs), four primary low-skew global clock nets and 24 secondary local clock nets for advanced timing control.
  • Programmability & configuration — SRAM-based, in-system configurable architecture with unlimited reprogramming and multiple programming modes for iterative development and field updates.
  • Package & supply — Surface-mount 256-BBGA (supplier package: 256-PBGA, 27×27 mm); nominal supply range 2.375 V to 2.625 V.
  • Commercial temperature grade & compliance — Rated for 0°C to 85°C operation and RoHS compliant for standard commercial applications.

Typical Applications

  • Embedded control and logic — Implement custom control logic, state machines, and glue logic where reprogrammability and on-chip memory reduce external parts count.
  • Interface bridging — Use multi-standard SelectIO and abundant I/O to bridge between disparate buses and memories, including direct connections to compatible ZBT RAM devices.
  • High-speed prototyping — Fast in-system reconfiguration enables iterative hardware development and validation of system-level designs.
  • Arithmetic and DSP support — Dedicated carry logic and multiplier support in the Virtex architecture speed arithmetic functions and data-path implementations.

Unique Advantages

  • High integration in a compact package: Combines programmable logic, embedded RAM, and plentiful I/O in a 256-ball BGA to reduce PCB area and BOM complexity.
  • Flexible embedded memory options: 32,768 bits of block RAM plus LUT-configurable RAM modes let you optimize memory architecture for control, buffering, and small data structures.
  • Deterministic clocking: Four dedicated DLLs and hierarchical clock nets provide precise clock control for timing-critical designs.
  • Broad I/O flexibility: Multi-standard SelectIO support across 180 I/Os simplifies interfacing to a wide range of external devices and memory types.
  • In-system reprogrammability: SRAM-based configuration supports unlimited reprogramming and multiple programming modes to accelerate development and field updates.
  • Development ecosystem support: Supported by established FPGA development systems for design flow, simulation, and place-and-route.

Why Choose XCV50-6BG256C?

The XCV50-6BG256C offers a balanced mix of programmable logic capacity, embedded memory, and I/O flexibility in a RoHS-compliant surface-mount package. Its SRAM-based architecture and on-chip clock-management resources make it well-suited for designs that require iterative development, in-system updates, and precise timing control.

This device is appropriate for engineers and teams building commercial embedded systems, protocol bridges, prototype platforms, and arithmetic-accelerated logic where a compact, reconfigurable solution with established development tool support is required.

Request a quote or submit an RFQ to receive pricing and availability information for the XCV50-6BG256C. Our team will provide the details you need to evaluate this device for your design.
