MC9328MXLVM15R2

The MC9328MXLVM15R2 is an i.MXL family microprocessor from NXP Semiconductors featuring a single ARM920T 32‑bit core running at 150 MHz. It combines CPU performance with a broad set of on‑chip system functions to address personal and portable embedded applications that require integrated peripherals and power management.

This device delivers a compact, surface‑mount 256‑contact PBGA (14×14) package with on‑chip memory controllers and peripheral interfaces—enabling simplified board design for handheld, multimedia and other embedded systems operating in commercial temperature environments.

Key Features

• Processor Core  ARM920T 32‑bit core, single‑core configuration operating at 150 MHz.
• Memory and Bus  Integrated SDRAM controller and AHB-to-IP bus interfaces to support external memory and system peripherals.
• Display and Multimedia  On‑chip LCD controller and Video Port support for user‑interface and display applications; includes a Multimedia Accelerator (MMA) as noted in product documentation.
• Storage and Host Controllers  MMC/SD host controller and Memory Stick® host controller for removable storage interfacing.
• Connectivity and Serial Interfaces  USB device, I2C bus module, SPI, two UARTs, SSI/I2S and other serial interfaces for diverse peripheral connectivity.
• System and Timing  DPLL clock and power control module, watchdog timer, real‑time clock (RTC), PWM and multiple general‑purpose timers for system control and power management.
• Direct Memory Access  On‑chip DMAC to accelerate data movement and offload the CPU for improved system efficiency.
• Package and Mounting  256‑contact PBGA (14×14) / 256‑LFBGA surface‑mount package tailored for compact embedded boards.
• Operating Range & Compliance  Commercial temperature range 0 °C to 70 °C and RoHS‑compliant construction.

Typical Applications

• Portable multimedia devices  Integrated LCD controller, video port and storage host controllers enable compact handheld multimedia products with display and removable storage.
• Handheld terminals and consumer electronics  On‑chip USB device, serial interfaces and SDRAM controller simplify designs for user interfaces and data I/O.
• Embedded control and instrumentation  Timers, PWM, RTC, watchdog and DMA provide the peripheral set needed for embedded control, monitoring and data capture applications.

Unique Advantages

• Highly integrated peripheral set: On‑chip LCD controller, USB device, MMC/SD and Memory Stick host controllers reduce external BOM and board complexity.
• System timing and power control: DPLL clock and power control module plus low‑level timers and RTC enable flexible power and clock management strategies.
• Compact surface‑mount package: 256‑contact PBGA (14×14) lets designers implement a full‑featured processor solution in space‑constrained products.
• Commercial operating range and RoHS compliance: Designed for 0 °C to 70 °C operation with RoHS‑compliant materials for mainstream embedded deployments.
• On‑chip DMA and peripherals: DMAC, UARTs, SPI, I2C and SSI/I2S accelerate I/O and multimedia tasks while offloading the CPU.

Why Choose MC9328MXLVM15R2?

The MC9328MXLVM15R2 positions a standard ARM920T core alongside a broad set of integrated system functions to deliver a balanced combination of performance and integration for portable and embedded products. Its 150 MHz core, on‑chip SDRAM controller, display and storage host controllers, plus extensive serial interfaces make it well suited to compact multimedia, handheld and control applications where board space and component count matter.

Comes with detailed technical documentation and package information to support design and implementation. The device’s integrated features and commercial temperature range provide a practical, documented platform for developers targeting mainstream embedded applications.

Request a quote or submit an inquiry to get pricing and availability details for the MC9328MXLVM15R2.
