MC9328MXLVP15

The MC9328MXLVP15 is an i.MXL series embedded microprocessor from NXP Semiconductors built around an ARM920T core. It delivers a 32‑bit single‑core processing engine operating at 150 MHz with integrated system functions targeted at embedded and portable applications.

Designed for portable and embedded products that require integrated peripherals, display control and memory interfaces, the device combines processing performance with on‑chip controllers and power management features to simplify system design and reduce board-level complexity.

Key Features

• Core ARM920T 32‑bit core running at 150 MHz, suitable for embedded applications requiring deterministic control and general‑purpose processing.
• Memory and Memory Controller Integrated SDRAM controller to interface with external SDRAM devices and streamline memory subsystem design.
• Display and Graphics I/O On‑chip LCD controller for direct display interfacing in portable and user‑interface applications.
• Peripheral Interfaces Built‑in USB device support (USB 1.x), I2C bus module, SPI, UARTs and MMC/SD and Memory Stick host controllers to support common peripheral and storage needs.
• Multimedia and DMA Multimedia Accelerator (MMA) and a Direct Memory Access Controller (DMAC) for efficient data movement and multimedia handling in resource‑constrained systems.
• Timing and System Control Includes real‑time clock (RTC), watchdog timer, multiple timers/counters and PWM channels for precise timing and control functions.
• Power and Clock Management DPLL clock and power control module and on‑chip power management features to support optimized power usage in portable designs.
• Package and Mounting Supplied in a compact 225‑MAPBGA (13×13) surface‑mount package for space‑constrained boards.
• Operating Conditions Rated for commercial temperature range of 0 °C to 70 °C and RoHS compliant.

Typical Applications

• Portable multimedia devices — Integrated LCD controller, MMC/SD and USB device support make the device suitable for handheld players and portable consumer electronics that require local storage and display.
• Handheld terminals and data capture — UARTs, I2C, SPI and on‑chip DMA enable responsive user interfaces and efficient peripheral communication in handheld instruments.
• Embedded display controllers — The LCD controller and ARM920T core provide a compact foundation for embedded systems with graphical user interfaces.
• Integrated storage hosts — Built‑in MMC/SD and Memory Stick host controllers simplify designs that need removable storage or local media support.

Unique Advantages

• Highly integrated peripheral set: On‑chip LCD controller, USB device, MMC/SD and Memory Stick host controllers reduce external components and BOM complexity.
• Efficient data handling: DMA and multimedia accelerator components offload data‑movement and multimedia tasks from the CPU, improving system efficiency.
• Compact packaging: The 225‑MAPBGA (13×13) surface‑mount package enables space‑efficient board layouts for portable and embedded designs.
• Power and clock control: DPLL and on‑chip power management features help optimize power use in battery‑sensitive applications.
• Commercial temperature rating and RoHS compliance: Specified operation from 0 °C to 70 °C and RoHS compliance support standard commercial deployments and regulatory requirements.

Why Choose MC9328MXLVP15?

The MC9328MXLVP15 combines an ARM920T core with a comprehensive set of integrated peripherals and system controllers to deliver a compact, easy‑to‑integrate platform for embedded and portable designs. Its combination of display support, storage host controllers, serial interfaces and power management features helps reduce system complexity and component count.

This part is well suited for designers targeting consumer portable and embedded user‑interface applications that require a balance of processing capability and integrated system functions, enabling faster time‑to‑market and streamlined hardware layouts.

Request a quote or submit a procurement inquiry to source MC9328MXLVP15 for your next embedded design project.
