XC6VLX365T-2FFG1759I
| Part Description |
Virtex®-6 LXT Field Programmable Gate Array (FPGA) IC 720 15335424 364032 1759-BBGA, FCBGA |
|---|---|
| Quantity | 749 Available (as of October 8, 2026) |
| Product Category | Field Programmable Gate Array (FPGA) |
|---|---|
| Manufacturer | AMD |
| Manufacturing Status | Active |
| Manufacturer Standard Lead Time | 12 Weeks |
| Datasheet |
Specifications & Environmental
| Device Package | 1759-FCBGA (42.5x42.5) | Grade | Industrial | Operating Temperature | -40°C – 100°C | ||
|---|---|---|---|---|---|---|---|
| Package / Case | 1759-BBGA, FCBGA | Number of I/O | 720 | Voltage | 950 mV - 1.05 V | ||
| Mounting Method | Surface Mount | RoHS Compliance | ROHS3 Compliant | REACH Compliance | REACH Unaffected | ||
| Moisture Sensitivity Level | 4 (72 Hours) | Number of LABs/CLBs | 28440 | Number of Logic Elements/Cells | 364032 | ||
| Number of Gates | N/A | ECCN | 3A001A7A | HTS Code | 8542.39.0001 | ||
| Qualification | N/A | Total RAM Bits | 15335424 |
Overview of XC6VLX365T-2FFG1759I – Virtex®-6 LXT Field Programmable Gate Array (FPGA)
The XC6VLX365T-2FFG1759I is a Virtex®-6 LXT field programmable gate array from AMD provided in a 1759-FCBGA package. It is an industrial-grade, surface-mount FPGA that combines high logic density, substantial on-chip memory, and a large I/O count for demanding embedded designs.
With 364,032 logic elements, approximately 15.33 Mbits of embedded memory, and up to 720 I/O, this device is suited to applications that require significant programmable logic, wide I/O connectivity, and operation across an industrial temperature range. The device operates from a core supply of 950 mV to 1.05 V and is RoHS compliant.
Key Features
- Core and Density — 364,032 logic elements provide substantial programmable logic capacity for complex digital designs and high-density implementations.
- Embedded Memory — Approximately 15.33 Mbits of on-chip RAM to support data buffering, lookup tables, and memory-intensive processing tasks.
- I/O Resources — Up to 720 I/O pins to support extensive peripheral connectivity, parallel interfaces, and multi-channel systems.
- Power — Core voltage supply range of 950 mV to 1.05 V to match system power rails and design requirements.
- Package & Mounting — 1759-BBGA / 1759-FCBGA package (supplier device package: 1759-FCBGA (42.5x42.5)) in a surface-mount form factor for compact system integration.
- Temperature & Grade — Industrial grade with an operating temperature range of -40 °C to 100 °C for deployment in temperature-demanding environments.
- Compliance — RoHS compliant, supporting regulatory requirements for lead-free assemblies.
Typical Applications
- High-density digital processing — Use the large logic capacity and embedded memory for data-path acceleration, parallel processing, and FPGA-based computation.
- Interface aggregation and bridging — Leverage the 720 I/O pins to connect multiple peripherals, implement protocol bridging, or consolidate interface logic on a single device.
- Industrial control systems — Industrial-grade temperature range and rugged package make the device suitable for control, automation, and motor-drive related logic functions.
- Prototyping and system integration — High logic density and on-chip memory enable complex prototype implementations and integration of multiple functions into one FPGA.
Unique Advantages
- High logic capacity: 364,032 logic elements let designers implement large, complex logic hierarchies without partitioning across multiple devices.
- Substantial on-chip memory: Approximately 15.33 Mbits of embedded RAM reduces dependence on external memory for many buffering and LUT needs.
- Extensive I/O count: Up to 720 I/O pins simplify system-level connectivity and reduce the need for external multiplexing or expansion logic.
- Industrial temperature rating: -40 °C to 100 °C operation supports deployment in temperature-challenging environments.
- Compact, surface-mount package: 1759-FCBGA packaging offers a high-density footprint for space-constrained boards.
- RoHS compliance: Meets lead-free assembly requirements for controlled manufacturing processes.
Why Choose XC6VLX365T-2FFG1759I?
The XC6VLX365T-2FFG1759I positions itself as a high-density, feature-rich FPGA for designs that demand a combination of large programmable logic capacity, significant embedded memory, and broad I/O connectivity within an industrial temperature envelope. Its surface-mount 1759-FCBGA package supports compact board layouts while maintaining the resources needed for complex system functions.
Choose this device for projects that require substantial on-chip resources and reliable operation across -40 °C to 100 °C. It is well suited to engineers developing integrated systems that consolidate multiple functions into a single programmable device and need a device with clear, verifiable hardware characteristics.
Request a quote or submit an inquiry for the XC6VLX365T-2FFG1759I to receive pricing and availability information for your design and procurement needs.
