XC7K410T-2FBG900C
| Part Description |
Kintex®-7 Field Programmable Gate Array (FPGA) IC 500 29306880 406720 900-BBGA, FCBGA |
|---|---|
| Quantity | 976 Available (as of October 8, 2026) |
| Product Category | Field Programmable Gate Array (FPGA) |
|---|---|
| Manufacturer | AMD |
| Manufacturing Status | Active |
| Manufacturer Standard Lead Time | 16 Weeks |
| Datasheet |
Specifications & Environmental
| Device Package | 900-FCBGA (31x31) | Grade | Commercial | Operating Temperature | 0°C – 85°C | ||
|---|---|---|---|---|---|---|---|
| Package / Case | 900-BBGA, FCBGA | Number of I/O | 500 | Voltage | 970 mV - 1.03 V | ||
| Mounting Method | Surface Mount | RoHS Compliance | ROHS3 Compliant | REACH Compliance | REACH Unaffected | ||
| Moisture Sensitivity Level | 4 (72 Hours) | Number of LABs/CLBs | 31775 | Number of Logic Elements/Cells | 406720 | ||
| Number of Gates | N/A | ECCN | 3A991D | HTS Code | 8542.39.0001 | ||
| Qualification | N/A | Total RAM Bits | 29306880 |
Overview of XC7K410T-2FBG900C – Kintex®-7 FPGA, 900-FCBGA
The XC7K410T-2FBG900C is a Kintex®-7 field programmable gate array (FPGA) IC from AMD, offered in a 900-ball FCBGA package. It combines a high count of logic resources with significant on-chip memory and broad I/O capability for board-level integration.
With 406,720 logic elements and approximately 29.3 Mbits of embedded memory, this commercial-grade device is suited to designs that require substantial logic density, embedded storage, and a large number of interface pins while operating within a standard commercial temperature range.
Key Features
- Logic Capacity 406,720 logic elements provide substantial programmable fabric for complex digital functions and custom acceleration.
- Embedded Memory Approximately 29.3 Mbits of on-chip RAM support buffering, data storage, and memory-intensive logic implementations.
- I/O Count 500 I/O pins enable extensive connectivity to external devices, sensors, and high-speed interfaces at the board level.
- Package and Mounting Supplied in a 900-FCBGA (31×31) package with surface-mount mounting for compact, board-level deployment.
- Power Supply Range Operates with a core voltage supply in the range of 0.97 V to 1.03 V to match system power rails and design constraints.
- Temperature and Grade Commercial grade operation from 0 °C to 85 °C for standard consumer and industrial electronics applications.
- Regulatory Status RoHS compliant to meet lead-free and restricted-substance requirements in manufacturing.
Typical Applications
- Logic-Intensive Acceleration High logic capacity supports custom compute blocks, signal processing engines, and hardware accelerators.
- Memory-Dependent Designs On-chip RAM is useful for buffering, packet processing, and intermediate data staging in real-time systems.
- High Pin-Count Interface Systems 500 I/O pins enable multi-channel I/O, interface bridging, and extensive peripheral integration on a single device.
Unique Advantages
- High Logic Density: 406,720 logic elements allow consolidation of complex functions into a single FPGA, reducing system component count.
- Substantial Embedded Memory: Approximately 29.3 Mbits of on-chip RAM reduces reliance on external memory and lowers system latency.
- Extensive I/O: 500 I/O pins provide flexibility for multi-protocol designs and numerous peripheral connections.
- Compact, Board-Ready Package: 900-FCBGA (31×31) surface-mount package supports dense PCB layouts and streamlined assembly.
- Commercial Temperature Range: Rated 0 °C to 85 °C to match typical consumer and commercial deployment environments.
- RoHS Compliant: Meets lead-free manufacturing requirements for regulated markets.
Why Choose XC7K410T-2FBG900C?
The XC7K410T-2FBG900C positions itself as a high-capacity Kintex®-7 FPGA option for designs that require a blend of large logic resources, meaningful embedded memory, and broad I/O connectivity in a compact FCBGA package. Its commercial-grade temperature range and RoHS compliance make it suitable for a wide range of consumer and commercial electronics.
This device is well suited for developers and system designers tackling mid- to high-complexity FPGA implementations where on-chip memory and pin count directly impact system architecture and board-level integration.
If you would like pricing or availability, request a quote or submit an inquiry to receive further purchasing information and lead-time details.
