XC7K410T-3FFG900E
| Part Description |
Kintex-7 FPGA, XC7K410T, 406,720 Logic Cells, 1540 DSP, FFG900, Commercial |
|---|---|
| Quantity | 186 Available (as of October 8, 2026) |
| Product Category | Field Programmable Gate Array (FPGA) |
|---|---|
| Manufacturer | AMD |
| Manufacturing Status | Active |
| Manufacturer Standard Lead Time | 16 Weeks |
| Datasheet |
Specifications & Environmental
| Device Package | FFG900 | Grade | N/A | Operating Temperature | 0°C – 100°C | ||
|---|---|---|---|---|---|---|---|
| Package / Case | 900-BGA | Number of I/O | 500 | Voltage | 950 mV - 1.05 V | ||
| Mounting Method | Surface Mount | RoHS Compliance | Compliant | REACH Compliance | REACH Unaffected | ||
| Moisture Sensitivity Level | 4 | Number of LABs/CLBs | 254200 | Number of Logic Elements/Cells | 406720 | ||
| Number of Gates | N/A | ECCN | EAR99 | HTS Code | 8542.31.00.60 | ||
| Qualification | N/A | Total RAM Bits | 29306880 |
Overview of XC7K410T-3FFG900E – Kintex®-7 Field Programmable Gate Array (FPGA) IC
The XC7K410T-3FFG900E is a Kintex®-7 FPGA IC by AMD, delivered in a 900-ball FCBGA surface-mount package. It combines high logic capacity and on-chip memory with abundant I/O to support complex, integrated digital designs.
This device is targeted at designs that require high logic density, substantial embedded memory, and a wide I/O count, while operating within an extended-grade temperature range and a defined core voltage window.
Key Features
- Logic Capacity Provides 406,720 logic elements for implementing large-scale combinational and sequential logic functions.
- Embedded Memory Approximately 29.3 Mbits of on-chip RAM to support buffering, FIFOs, and local data storage.
- I/O Resources Up to 500 I/O pins to enable broad system interfacing and peripheral connectivity.
- Power and Core Voltage Core voltage range specified at 0.970 V to 1.03 V for defined power delivery and core operation.
- Package and Mounting 900-FCBGA (31×31) supplier device package / 900-BBGA, FCBGA package case; surface mount mounting type for PCB assembly.
- Operating Range and Grade Extended-grade operation across 0 °C to 100 °C for deployment in environments matching this temperature window.
- Compliance RoHS compliant to support regulatory requirements for lead-free assembly.
Typical Applications
- High-density digital logic Implement complex state machines, custom processors, and large logic functions using 406,720 logic elements.
- On-chip buffering and packet handling Exploit approximately 29.3 Mbits of embedded RAM for packet buffering, queues, and local data storage.
- Systems with extensive I/O Use the 500 available I/O pins to aggregate multiple peripherals, interfaces, and sensors on a single device.
- Extended-environment electronics Deploy in systems that operate within the 0 °C to 100 °C range and require extended-grade components.
Unique Advantages
- High logic density: 406,720 logic elements enable consolidation of large logic functions, reducing the need for multiple discrete FPGAs.
- Substantial on-chip memory: Approximately 29.3 Mbits of embedded RAM minimizes external memory dependencies and accelerates internal data paths.
- Generous I/O count: 500 I/O pins permit extensive peripheral integration and flexible board-level connectivity.
- Defined core voltage range: The 0.970 V to 1.03 V supply window provides clear guidance for power-supply design and voltage regulation.
- FCBGA surface-mount package: The 900-FCBGA (31×31) package supports compact PCB layouts while providing high pin density for complex systems.
- RoHS compliant: Meets lead-free assembly requirements for modern PCB manufacturing processes.
Why Choose XC7K410T-3FFG900E?
The XC7K410T-3FFG900E positions itself as a high-capacity FPGA option for designers needing significant logic resources, on-chip memory, and a large I/O count in a single surface-mount package. Its extended-grade temperature range and defined core voltage make it suitable for systems that operate within those environmental and power envelopes.
Manufactured by AMD and supplied in a 900-FCBGA (31×31) package, this device is appropriate for projects that prioritize integration of complex logic and substantial embedded RAM on a single device while maintaining RoHS compliance and standard surface-mount assembly practices.
Request a quote or submit an inquiry to source XC7K410T-3FFG900E for your next design and receive pricing and availability information tailored to your requirements.
