XCKU11P-L1FFVD900I
| Part Description |
Kintex® UltraScale+™ Field Programmable Gate Array (FPGA) IC 408 53964800 653100 900-BBGA, FCBGA |
|---|---|
| Quantity | 1,958 Available (as of October 8, 2026) |
| Product Category | Field Programmable Gate Array (FPGA) |
|---|---|
| Manufacturer | AMD |
| Manufacturing Status | Active |
| Manufacturer Standard Lead Time | 16 Weeks |
| Datasheet |
Specifications & Environmental
| Device Package | 900-FCBGA (31x31) | Grade | Industrial | Operating Temperature | -40°C – 100°C | ||
|---|---|---|---|---|---|---|---|
| Package / Case | 900-BBGA, FCBGA | Number of I/O | 408 | Voltage | 698 mV - 876 mV | ||
| Mounting Method | Surface Mount | RoHS Compliance | ROHS3 Compliant | REACH Compliance | REACH Unaffected | ||
| Moisture Sensitivity Level | 4 (72 Hours) | Number of LABs/CLBs | 37320 | Number of Logic Elements/Cells | 653100 | ||
| Number of Gates | N/A | ECCN | 3A991D | HTS Code | 8542.39.0001 | ||
| Qualification | N/A | Total RAM Bits | 53964800 |
Overview of XCKU11P-L1FFVD900I – Kintex® UltraScale+™ Field Programmable Gate Array (FPGA), 900-FCBGA
The XCKU11P-L1FFVD900I is an AMD Kintex® UltraScale+™ field programmable gate array (FPGA) supplied in a 900-ball FCBGA package. It provides a high-density programmable logic fabric combined with substantial embedded memory and a large count of I/O suitable for industrial-grade applications.
With 653,100 logic elements, approximately 54 Mbits of on-chip RAM and 408 I/O pins, this device targets designs that require high integration, reconfigurable logic capacity and operation across an industrial temperature range.
Key Features
- Logic Capacity 653,100 logic elements to implement complex, high-density digital designs.
- Embedded Memory Approximately 54 Mbits of on-chip RAM (53,964,800 bits) for buffering, state storage and data-path implementations.
- I/O Density 408 I/O pins to support wide parallel interfaces and multiple external connections.
- Power Supply Operates from a supply range of 698 mV to 876 mV, enabling compatibility with supported core power architectures.
- Package and Mounting 900-ball FCBGA (31 × 31) package, surface-mount mounting type for compact, high-pin-count board designs.
- Industrial Temperature Range Rated for operation from −40 °C to 100 °C for deployment in industrial environments.
- Manufacturer Designed and produced by AMD.
- Standards Compliance RoHS compliant.
Typical Applications
- Industrial Automation and Control Use the industrial-grade temperature range and high I/O count for control logic, real-time interfacing and system orchestration.
- High-Density Logic and Data Processing Employ the large logic element count and embedded RAM for complex digital signal processing, custom acceleration or algorithm implementation.
- Interface Aggregation and Bridging Leverage 408 I/O pins to consolidate multiple external interfaces or implement high-pin-count protocol bridging on a single device.
Unique Advantages
- High Integration Density: 653,100 logic elements enable consolidation of multiple functions into a single FPGA, reducing overall system BOM.
- Substantial On-Chip Memory: Approximately 54 Mbits of embedded RAM supports large buffers and stateful logic without external memory.
- Extensive I/O Connectivity: 408 I/O pins provide flexibility for parallel interfaces, sensors, actuators and external peripherals.
- Industrial Reliability: Rated for −40 °C to 100 °C operation to meet the demands of industrial environments.
- Compact High-Pin-Count Package: 900-FCBGA (31×31) package offers a small footprint with high pin density for space-constrained boards.
- Regulatory Compliance: RoHS compliant for environmental and manufacturing process compatibility.
Why Choose XCKU11P-L1FFVD900I?
The XCKU11P-L1FFVD900I positions itself as an industrial-grade, high-density FPGA solution for designs requiring substantial logic resources, embedded memory and broad I/O connectivity. Its combination of 653,100 logic elements, approximately 54 Mbits of on-chip RAM and 408 I/O pins enables consolidation of complex interfaces and data processing into a single reconfigurable device.
This AMD Kintex® UltraScale+™ FPGA is suited to engineers and system designers developing industrial control, high-density logic implementations or interface aggregation solutions who require long-term robustness, compact high-pin-count packaging and compliance with RoHS requirements.
Request a quote or submit a pricing inquiry for the XCKU11P-L1FFVD900I to evaluate availability and delivery for your next design.
