EP1SGX10DF672C6N

The EP1SGX10DF672C6N is a Stratix® GX Field Programmable Gate Array (FPGA) from Altera, offered in a 672-ball BGA package. It delivers a balanced mix of programmable logic, on-chip memory, and high I/O density for complex digital designs.

With 10,570 logic elements, approximately 0.92 Mbits of embedded RAM, and 362 user I/O pins, this commercial-grade, RoHS-compliant device is suited to applications that require mid-range logic capacity, significant embedded memory, and high pin-count connectivity within a compact surface-mount footprint.

Key Features

• Core Logic  10,570 logic elements for implementing custom digital logic, control functions, and programmable signal flow.
• Embedded Memory  Approximately 0.92 Mbits of on-chip RAM to support buffering, lookup tables, and localized data storage.
• High I/O Density  362 user I/O pins to accommodate multiple parallel interfaces, board-level signaling, and peripheral connections.
• Package  672-BGA (672-FBGA, 27×27 mm) surface-mount package for high-density board integration while maintaining a small PCB footprint.
• Power  Nominal core supply range of 1.425 V to 1.575 V to match system power rails and design constraints.
• Operating Range  Commercial operating temperature from 0 °C to 85 °C, suited for standard commercial environments.
• Regulatory  RoHS-compliant design for environmentally conscious assembly and supply chain requirements.

Typical Applications

• Custom digital systems  Implement control logic, state machines, and protocol handling using mid-range programmable resources and embedded RAM.
• High-pin-count interface boards  Use the 362 I/O pins to connect multiple peripherals, parallel interfaces, or board-to-board signaling in compact systems.
• Prototyping and evaluation  Rapidly iterate FPGA-based prototypes requiring a balance of logic elements and embedded memory in a standard surface-mount package.

Unique Advantages

• Balanced logic and memory capacity: 10,570 logic elements combined with approximately 0.92 Mbits of RAM provide flexible resources for mixed control and data tasks.
• High I/O availability: 362 user I/O pins reduce the need for external multiplexing and simplify connections to sensors, interfaces, and peripherals.
• Compact BGA package: The 672-FBGA (27×27) package enables dense placement on modern PCBs while supporting high pin counts.
• Commercial-grade suitability: Specified operating range of 0 °C to 85 °C and RoHS compliance align with standard commercial product requirements.
• Controlled core supply range: The 1.425 V to 1.575 V supply window provides predictable power behavior for system-level power planning.

Why Choose EP1SGX10DF672C6N?

The EP1SGX10DF672C6N positions itself as a versatile mid-range Stratix® GX FPGA option for designers who need a practical balance of logic capacity, embedded memory, and high I/O counts in a compact surface-mount package. Its specification set supports a wide range of commercial electronic designs where on-chip resources and pin density simplify board-level architecture.

For engineering teams focused on scalable, reprogrammable digital logic, this device offers a clear combination of integration and predictable electrical and thermal limits, backed by Altera's Stratix GX platform lineage.

Request a quote or submit an inquiry to discuss availability, pricing, and delivery for the EP1SGX10DF672C6N.
